상세 설명

System

 -. Fully automated, random access analyzer for Clinical Chemistry and Homogeneous   Immunology (HIA).

Sample throughput

 -. Up to 300 samples/hr (theoretical max)

Test throughput (Theoretical max)

 -. 300 tests/hr for photometry tests only 480 tests/hr for only ISE tests

 Number of channels (Reagent slots)

-.  42 cassette slots 3 channels on ISE module

 Programmable parameters

 -. max. 117 photometric 3 ISE tests, 8 formulas, 3 serum indices

Sample types

 -. Serum, Plasma, Urine, CSF, Whole Blood (HbA1c only)

Sample input (Sample disk)

-. Load capacity:  total 110 positions

                              55 positions on the outer ring

                              55 positions on the inner ring (outer & inner ring barcode read, sample detection available)

 -. STAT:  real STAT interrupt is available

 -. continuous operation:  additional sample loading during operation

 Sample barcode types

-. Code 128 Codabar (NW 7) Interleaved 2 of 5 Code 39

 System interfaces

 -. RS 232 serial interface, bi-directional Interface to cobas link (TeleService and automatic download of applications and package inserts)
